Programmable Control Mobile Asphalt Plants for Asphalt Concrete Full Automatic
30Tons / Hour Capacity Mobile Asphalt Batching Plant QLB-30 With 1500kgs Feeder Hopper Capacity
30 TPH Mobile Asphalt Batching Plant QLB-30 With Oil Burner / Coal Burner
Specifications:
| Capacity | 30 tph |
| Fuel consumpution | 5.5-7.5kg/t |
| Feeder hopper capacity | 1500kgs |
| Asphalt output | 1500kgs |
| Aggregate size | <=50mm |
| Aggregate Bins | 5M3x4 each, accumulative scale |
| Accuracy | Aggregate | ≤2000kg±3% |
| | Fly ash | ≤180kg±2％ |
| | Asphalt | ≤180kg±2% |
| Product temperature | 120~165 ℃,adjustable |
| Total consumption | 97 kW (Oil burner) |
QLB seriesmodular positive asphalt concrete mixing equipments is manufacturered
based on foreign countries advanced technology,the machine structure is simple
compact with high automation and stabilization. the oil aggregate ration is stable,the
finish products quality is high. it realizes efficiency and good economic returns.
1.The burner adopted the auto fuel technology and the latest pulverized coal jet
technology. it realizes the automatic ignition,compete combusition,high thermal
sfficiency.
2.The main parts adopt independent combination. control by programmable control
program to ensure the centralized control is easy.
3.it is easy to set the drying time so the drying cylinder can reach temprature
standards to dry even the wet mineral aggregate and ensure the quality of
asphalt concrete requirements.
4.oil aggregate ratio is very accutate by using asphalt spray .
5.using double drum drying ore materila to short drying time units and improve
efficiency.
6.It is high full-automatic,save human labor
7. Drying cyclinder structure using heat-resistant and wearable boller steel plate.
Using the gear-driven and four cast iron supporting idlers to ensure the work speed
reposeful. Intermal blades can mix the material general also reduce the heat lost.
When the aggregate reach desired dry dry index , the drum will discharge the
concrete to positive mixer.
8.The finished products is in high quality and stable performance, as the machine
used the positive mixing, all kinds of the materials can be mixed together with
asphalt better and ensure the high quality, asphalt concrete.
