2WD Diesel Mini Concrete 2 Tonne Dumper For Site Works / Municipal Engineering / Underground Mines

Name: 2WD Diesel Mini Concrete 2 Tonne Dumper For Site Works Municipal Engineering Underground Mines
Brand: Visbull
Price: 6100 USD

Buy cheap 2WD Diesel Mini Concrete 2 Tonne Dumper For Site Works / Municipal Engineering / Underground Mines product

Brand Name : Visbull

Model Number : SD20

Certification : CE/SGS

Place of Origin : China

MOQ : 1unit

Price : US$6100-US$6300 per unit

Payment Terms : L/C, D/A, D/P, T/T, Western Union, MoneyGram

Supply Ability : 1,000pcs per month

Delivery Time : 25-30 working days after received your advance payment

Packaging Details : Nude packing in container.

Payload : 2000kg

Skip Capacity : 1.0m3

Chassis : Rigid Or Articulated Frame

Engine : CHANGFA,385

Driving : 4*2 Or 4*4

Gradient : 25%

Turning Radius : 4m

Dimensions : 3058*1800*2100mm

Weight : 1500kgs

Starting System : Electric start,12volts battery

Color : Yellow

Rated Power : 32HP

Contact Now

2WD Diesel Mini Concrete 2 Tonne Dumper For Site Works / Municipal Engineering / Underground Mines

2tons Mini Dumper With Hydraulic Tipping Hopper

Specifications:

Model	SD20
Payload	2000kg
Diesel Engine	Twin cylinders, Water-cooling system with radiator
Rated Power	32hp/2600 rpm
Water capacity	800 ltr (28.3 cuf)
Struck capacity	1000 ltr (35.3 cuf)
Heaped capacity	1300 ltr (45.7 cuf)
Min.Out turning circle Radius	4.5 m
Min. Ground Clearance	200mm
Discharging Height	1247mm
Engine starting	Electric
Electric Battery	12 V, 75 amp.
Driver awning	Yes
Road speed	3.85 ~24.66 km/h
Reverse speed	3.15 km/h
Transmission	4 forward & 1 reverse gear
Clutch	Constant-contact, single disc, dry clutch
Tipping system	Hydraulic
Driving axle	4*2
Dimension	305817252360mm
Unladed weight	1490kg
Skip capacity	1.0m3

Description:

1 . Wheel type mini dumper
2 . With power steering and powerful 32HP engine , it's easier to move at slope or rugged area .
3 . with transmission for car , it's possible to change speed during travel.
4 . Efficiency of transportation by transportation , loading , unloading and dumping ability.
5 . 4*2 driving articular frame with hydraulic steering
6 . China made F3L912 air cooled diesel engine with Deutz technology / NB485 water engineering
diesel engine

Applications:

Dumpers are widely used in many different of site works , such as the construction industry, the factory
floor , battlefield ,protecting road section , the municipal engineering , underground mines and so on .

Competitive Advantage:

1 . As a low volume, short distance transport of bulk materials for small site dumpers, because of its easy
operation, small turning radius can be used in a narrow environment, etc,.
2 . Full Cover of Diesel Engine
3 . Strong and Heavy Duty Frame and Chassis
4 . Bucket can be full automatically tipped by hydraulic cylinder
5 . Direction change of dumper can be easily controlled by hydraulic steering wheel
